YF-3000 3 Ton Rough Terrain Forklift
| Item | Specification |
|---|---|
| Model | YF‑3000 |
| Rated Capacity | 3,000 kg |
| Load Center | 500 mm |
| Max. Lifting Height | 3,000‑7,000 mm |
| Fork Length | 1,070 mm |
| Overall Dimensions (L×W×H) | 3,800 × 1,720 × 2,200 mm |
| Engine Brand | Yunnei |
| Engine Model | YN490 (Diesel) |
| Rated Power | 42 kW |
| Transmission | Torque converter, high/low dual speed |
| Drive Type | 4WD |
| Tire Type | Off‑road pneumatic tires |
| Tire Size | 8.25‑15 (front & rear) |
| Ground Clearance | 250 mm |
| Turning Radius | 5,000 mm |
| Maximum Gradeability | 25% |
| Travel Speed | 0‑25 km/h |
| Operating Weight | ≈4,800 kg |
| Mast Type | Two‑stage (duplex), triplex optional |
| Fork Dimensions | 1,070 × 120 × 40 mm |
| Fuel Tank Capacity | 70 L |
| Hydraulic Tank Capacity | 45 L |
| Wheelbase | 2,100 mm |
| Track Width | 1,450 mm |
Yf-3000 Product Features
1. This 3 Ton Rough Terrain Forklift with renowned brand Yunnei engine paired with a larger hydraulic pump makes the machine more powerful and capable of operating in any harsh environment, suitable for various working conditions.
2. Thickened fuel tank, treated with pickling and phosphating, and powder-coated surface.
3. This Rough Terrain Forklift with Standard LCD instrument panel, plus a timer.
4. Torque converter with a 38cm diameter engine interface, resulting in greater torque and stronger power.
5. Beautiful machine appearance, with a three-stage painting process for a more glossy surface.
Why Choose Our 3 Ton Rough Terrain Forklift?
3-Ton Heavy Lifting Capacity
Designed to handle up to 3,000 kg of materials for construction sites, farms, warehouses, yards and industrial applications.
4WD All-Terrain Performance
Four-wheel drive and large off-road tires provide better traction on mud, gravel, sand, slopes and uneven ground.
High Ground Clearance
The elevated chassis helps reduce the risk of bottoming out when operating on rough terrain.
Powerful Diesel Engine
The 42 kW diesel engine delivers sufficient power for demanding outdoor material-handling operations.
Flexible Attachment Options
Forks, side shifters, buckets and other attachments can be configured according to different material-handling requirements.
Easy Maintenance
Key components are designed for convenient inspection and routine maintenance, helping reduce downtime.
Product Features
ENGINE
Various Well-known big brand engines to choose from, have excellent reliability and easy maintenance.
CAB
Ensure that the operator has a better view during loading operations and that the driver's seat is usually placed forward.
HYDRAULIC SYSTEM---
Adopting high-quality and efficient hydraulic systems to provide maximum power and faster work cycles, achieving higher productivity.
AXIS
High quality hydraulic shafts not only withstand heavy loads, but also convert high static hydraulic torque into off-road power, with excellent off-road performance, ensuring power supply for various complex roads.
DRIVE
It has good passability and off-road all-wheel drive. There is no difference between the axles, and large-diameter wide-base off-road tires are used.
Rough Terrain Forklift vs. Standard Forklift
| Feature | Rough Terrain Forklift | Standard Warehouse Forklift |
|---|---|---|
| Drive | 4WD | Usually 2WD |
| Terrain | Uneven / rough terrain | Flat floors |
| Ground Clearance | High | Low |
| Tires | Large pneumatic off-road tires | Solid/pneumatic tires |
| Typical Use | Construction, farms, yards | Warehouses |
| Traction | Strong | Moderate |
| Outdoor Capability | Excellent | Limited |
We support customizing various accessories you need, including common accessories such as Tipping bucket, Side shift, Bucket, Tipping fork, Free door clip, and Pitch fork and so on.
The product has passed European CE certification, fully meeting European market requirements; it also complies with Euro V emission standards and US EPA emission regulations, ensuring legal and compliant sales and use in overseas markets such as Europe and the United States.
FAQ
Q: What is the lifting capacity of this rough terrain forklift?
A: The YF‑3000 is rated for a maximum load capacity of 3,000 kg under the specified operating conditions.
Q: Is this forklift suitable for muddy or uneven terrain?
A: Yes. Equipped with large off‑road pneumatic tires and high ground clearance of 250 mm, this rough terrain forklift performs well on muddy, gravel, sloped and uneven construction‑site ground.
Q: Is the forklift 4‑wheel drive?
A: Yes, it adopts full 4WD (four‑wheel drive) system for stronger traction and better cross‑country performance in tough working sites.
Q: What engine does the forklift use?
A: It is fitted with Yunnei YN490 diesel engine, rated power 42 kW, reliable and fuel‑efficient for heavy‑duty outdoor work.
Q: What is the maximum lifting height?
A: Standard max lifting height ranges from 3000 mm to 7000 mm based on different mast configurations.
Q: Can the lifting height be customized?
A: Yes. We support custom‑made lifting height according to your actual site requirements, both two‑stage and three‑stage masts are optional.
Q: What attachments are available?
A: Multiple optional attachments are available, such as side shifter, fork positioner, bucket, clamps for bales / drums, etc. Please tell us your working needs for matching recommendations.
Q: Can you provide OEM service?
A: OEM service is supported. We can customize machine colors, logos, labels and partial configurations according to your requirements.
Q: What is the warranty period?
A: We provide 12‑month or 2000‑working‑hours warranty (whichever comes first). Core engine and hydraulic parts are covered under warranty against manufacturing defects.
Q: How do you ship the forklift overseas?
A: Normally shipped by sea in 20GP / 40HQ container. The forklift will be securely fixed inside the container; we can also arrange bulk vessel shipping for multiple‑unit orders.
